Brits Diagnostic Adaptor & Diagnostic CD List
Adaptors, Accesories & other Hardware
| Rover Part No | Land Rover Part No | Name / Description |
|---|---|---|
| DTC4002B | LRT5001 | T4 Interface Unit |
| DTC4003 | T4 Laptop with RDS Operating System | |
| DTC0001B | T1 -T3 Technical Interface Microlink (TIM Unit) | |
| DTC0006A | T1 -T3 Interface Box (Brick Box) | |
| DTC0007B | T1 -T3 Main Cable 1 | |
| DTC4007B | LRT5004A | T4 Main Cable 1 |
| DTC0008B | LRT5006A | MEMS Adaptor |
| DTC0013B | LRT5007A | Main Cable 2 |
| DTC0017A | MG / Rover CCU Adaptor | |
| DTC0019A | Lucas 5AS Adaptor | |
| DTC0020A | LRT5008A | Land Rover 14CUX Adaptor |
| DTC0022A | LRT5010A | Land Rover Air Suspension (avail. upon request) |
| DTC0023B | LRT5011A | Airbag Adaptor |
| DTC0027A | J1962 Data Link Connector (switchable) | |
| DTC0029A | ||
| DTC0057A | LRT5017A | J1962 Airbag Dongle |
| DTC0060A | J1962 Adaptor Yellow | |
| DTC0061A | J1962 Adaptor Blue | |
| DTC0062B | LRT5019A | J1962 Adaptor Green |
| DTC0063A | LRT5020A | J1962 Adaptor Black (Air Suspension Range Rover) |
| DTC0064A | J1962 Adaptor Grey | |
| DTC0065A | LRT5021A | J1962 Adaptor Red |
| DTC0066A | Loopback Connector (avail. upon request) | |
| DTC0071A | Integrity Test Harness (avail. upon request) | |
| DTT0002A | LRT5023A | Current Clamp |
Available English TestBook T4 CDs
We can supply a wide range of English-language diagnostic and application CDs for the original Rover and Land Rover TestBook T4 system.
The exact CD required depends on the vehicle, model year, TestBook configuration and software already installed.
| Series | CD Name | Vehicles covered / Description |
|---|---|---|
| MG and Rover | DRM0020U | MG, MGF, TF, ZR, ZS and ZT |
| DST00020 | MG, Rover and Rover TestBook application | |
| DXP0001G | MG ZT 260 | |
| Rover | DRR0009 | Mini, Maestro, Montego, Rover 100, 200 and 400 -> 04/1995 |
| DRE0008 | Mini, Maestro, Montego, Rover 100, 200 and 400 -> 2000 | |
| DST0CR1 | CityRover Diagnostic | |
| Microcheck | DRX0003Y | Microcheck for TestBook (All Vehicles < 1995) |
| Land Rover | DRG0025Z | Defender, Discovery, Discovery 2, Range Rover Classic, Range Rover and Freelander -> 2005 |
| DRL0014 | Defender, Discovery and Range Rover Classic -> 05/1996 | |
| Range Rover | DRF0006Z | Range Rover 1995 |
| DJL0D21Y | New Range Rover / Range Rover L322 | |
| Freelander | DRGTL36X | Freelander 2001 onwards |
| TestBook | DRO4001 | T4 Diagnostic Tool |
| DCD0L07 | HandHeld Tester Applications / Program Upload CD 07 | |
| Performance | DXPG002X | Diesel Power Upgrade |
| DXT002W | MG ZT / Rover 75 Diesel Tune and Language Map Upgrade | |
| RDS System | RDS 3.11 | RDS System install CD for T1, T2 & T3 |
| RDS 4.04 | RDS System CD for T1, T2 & T3 (Update to latest Version) | |
| RDS 5.06 | RDS System CD for T4 (Latest combined Version for Rover & Land Rover) | |
| RDS 6.0 | RDS System CD for T4 (Rover or Land Rover install) | |
| RDS 7.0 | RDS System CD for T4 (Rover or Land Rover install) | |
| RDS 7.06 | RDS System CD for T4 (Rover or Land Rover install) | |
| T4 Mobile+ | T4 Mobile+ Update | |
| DTC0066A | Loopback Connector (avail. upon request) | |
| DTC0071A | Integrity Test Harness (avail. upon request) | |
| DTT0002A | LRT5023A | Current Clamp |
About the TestBook CD codes
The first three letters identify the CD series. The fourth letter normally identifies the language. Higher numbers usually indicate a later release within the same series, while the final letter identifies the revision sequence.
Only the latest available English release from each relevant series is listed.
Looking for a specific TestBook CD?
Send us the exact CD code, details of your TestBook configuration and the vehicle models you need to diagnose.
